Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
812 IEC101 Link
Address Size
X
--- View Modify NA 1 1 2
•This is the Com 1 setting for the number of octets to be used for the value of the link
address.
812 IEC101 Common
Address Size
X
--- View Modify NA 1 1 2
•This is the Com 1 setting for the number of octets to be used in the value of the common
address.
812 IEC101 Object
Address Size
X
--- View Modify NA 2 1 3
•This is the Com 1 setting for the number of octets to be used in the value of the object
address.
812 IEC101 Cause of
Transmit Size
X
--- View Modify NA 1 1 2
•This is the Com 1 setting for the number of octets to be used in the cause of
transmission indication.
812 IEC101 Single
Command Op Mode
SBE
--- View Modify NA SBE NA NA
•This is the Com 1 setting that defines if the control will respond directly (Direct mode)
to Single Command Operation commands or if a "select" is required before "execution" (SBE
mode).
•The available options are: Direct; SBE.
812 IEC101 Select
Before Exec Time
XXXXX mSec
MilliSec View Modify NA 5000 0 65535
•This is the Com 1 setting that determines the amount of time that can elapse between a
"select" and "execute" command for Single Command Operations in systems that employ a
select-before-execute mode.
812 IEC101 User Map
Selection
CL-7 Default
--- View Modify NA
CL-7
Default
NA NA
•The selection of the active IEC101 map for Com 1. The available options are: User 1;
User 2; CL-7 Default; CL-7 Default Events; CL-7 Advanced; CL-6 Default; CL-6 Default
Events; CL-7 3Ph Default; CL-7 3Ph Default Evt; CL-7 3Ph Advanced.
813 IEC104 Server
Listen Port
XXXXX
--- View Modify NA 2404 1 65535
•This is the Com 1 setting for the IP port number that will be monitored for connections.
813 IEC104 Common
Address
XXXXX
--- View Modify NA 2 1 65535
•This is the Com 1 setting that identifies the station address, where the station is
comprised of all of a device's links for Com 1.
107
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
