Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
489 Voltage Limiter
Delay
XX Seconds
Seconds View Modify NA 10 1 60
•The Voltage Limiter Delay for Alternate Configuration 1.
490 Time Between
Taps
XX Seconds
Seconds View Modify NA 0 0 10
•The Voltage Limiter Time Between Taps for Alternate Configuration 1.
491 Tap To Neutral
Off
--- View Modify NA Off NA NA
•The Tap to Neutral setting for Alternate Configuration 1.
492 Bias Co-Gen Alt
Mode
Locked Reverse
--- View Modify NA
Locked
Reverse
NA NA
•The Bias Co-generation Alt Mode setting for Alternate Configuration 1. See FC 58.
500 Forward
Set Voltage
XXX.X Volts
Volts View Modify NA 120.0 100.0 135.0
•Forward Set Voltage for Alternate Configuration 2.
501 Forward
Bandwidth
X.X Volts
Volts View Modify NA 2.0 1.0 6.0
•Forward Bandwidth for Alternate Configuration 2.
502 Forward
Time Delay
XXX Seconds
Seconds View Modify NA 45 5 180
•Forward Time Delay for Alternate Configuration 2.
503 Fwd Line Drop
Comp. Resistance
XX.X Volts
Volts View Modify NA 0.0 -96.0 96.0
•Forward Line Drop Compensation Resistance for Alternate Configuration 2.
504 Fwd Line Drop
Comp. Reactance
XX.X Volts
Volts View Modify NA 0.0 -96.0 96.0
•Forward Line Drop Compensation Reactance for Alternate Configuration 2.
505 Reverse
Set Voltage
XXX.X Volts
Volts View Modify NA 120.0 100.0 135.0
•Reverse Set Voltage for Alternate Configuration 2.
506 Reverse
Bandwidth
X.X Volts
Volts View Modify NA 2.0 1.0 6.0
•Reverse Bandwidth for Alternate Configuration 2.
507 Reverse
Time Delay
XXX Seconds
Seconds View Modify NA 45 5 180
•Reverse Time Delay for Alternate Configuration 2.
89
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
