Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
508 Rev Line Drop
Comp. Resistance
XX.X Volts
Volts View Modify NA 0.0 -96.0 96.0
•Reverse Line Drop Compensation Resistance for Alternate Configuration 2.
509 Rev Line Drop
Comp. Reactance
XX.X Volts
Volts View Modify NA 0.0 -96.0 96.0
•Reverse Line Drop Compensation Reactance for Alternate Configuration 2.
510 Control
Operating Mode
Sequential
--- View Modify NA Sequential NA NA
•The Control Operating Mode for Alternate Configuration 2.
511 Reverse Sensing
Mode
Locked Forward
--- View Modify NA
Locked
Forward
NA NA
•The Reverse Sensing Mode for Alternate Configuration 2.
512 Reverse Current
Sense Threshold
X %
% View Modify NA 1 1 5
•The Reverse Current Sense Threshold for Alternate Configuration 2.
513 Auto Operation
Blocking Status
Normal
--- View Modify NA Normal NA NA
•The Auto Operation Blocking Status for Alternate Configuration 2.
514 Voltage
Reduction Mode
Off
--- View Modify NA Off NA NA
•The Voltage Reduction Mode for Alternate Configuration 2.
515 Local/Digital
Reduction Value
XX.X %
% View Modify NA 0.0 0.0 10.0
•The Local/Digital Reduction Value for Alternate Configuration 2.
516 Remote #1 Value
XX.X %
% View Modify NA 0.0 0.0 10.0
•The Remote latch #1 Voltage Reduction Value for Alternate Configuration 2.
517 Remote #2 Value
XX.X %
% View Modify NA 0.0 0.0 10.0
•The Remote latch #2 Voltage Reduction Value for Alternate Configuration 2.
518 Remote #3 Value
XX.X %
% View Modify NA 0.0 0.0 10.0
•The Remote latch #3 Voltage Reduction Value for Alternate Configuration 2.
519 # of Pulse
Reduction Steps
XX
--- View Modify NA 0 0 10
•The Remote Pulse Voltage Reduction number of steps for Alternate Configuration 2.
520 % of Voltage Red
Per Pulse Step
XX.X %
% View Modify NA 0.0 0.0 10.0
•The Remote Pulse Voltage Reduction % per step for Alternate Configuration 2.
90
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
