Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
521 Present Voltage
Reduction Step
XX
--- View NA NA NA NA NA
•The Remote Pulse Voltage Reduction Present Voltage Reduction Step for Alternate
Configuration 2.
522 SOFT-ADD-AMP
Limits
Off
--- View Modify NA Off NA NA
•The SOFT-ADD-AMP Limits feature enabled for Alternate Configuration 2.
523 SOFT-ADD-AMP
High Limit
XX
--- View Modify NA 16 NA NA
•The SOFT-ADD-AMP High Limit for Alternate Configuration 2.
524 SOFT-ADD-AMP
Low Limit
XX
--- View Modify NA -16 NA NA
•The SOFT-ADD-AMP Low Limit for Alternate Configuration 2.
525 Voltage Limiter
Mode
Off
--- View Modify NA Off NA NA
•Voltage Limiter Mode enabled for Alternate Configuration 2.
526 High Voltage
Limit
XXX.X Volts
Volts View Modify NA 130.0 120.0 135.0
•The Voltage Limiter High Limit for Alternate Configuration 2.
527 Low Voltage
Limit
XXX.X Volts
Volts View Modify NA 105.0 105.0 120.0
•The Voltage Limiter Low Limit for Alternate Configuration 2.
528 Voltage Limiter
Fast Resp. Delay
XX Seconds
Seconds View Modify NA 3 1 60
•The Voltage Limiter Fast Resp. Delay for Alternate Configuration 2.
529 Voltage Limiter
Delay
XX Seconds
Seconds View Modify NA 10 1 60
•The Voltage Limiter Delay for Alternate Configuration 2.
530 Time Between
Taps
XX Seconds
Seconds View Modify NA 0 0 10
•The Voltage Limiter Time Between Taps for Alternate Configuration 2.
531 Tap To Neutral
Off
--- View Modify NA Off NA NA
•The Tap to Neutral setting for Alternate Configuration 2.
532 Bias Co-Gen Alt
Mode
Locked Reverse
--- View Modify NA
Locked
Reverse
NA NA
•The Bias Co-generation Alt Mode setting for Alternate Configuration 2. See FC 58.
91
