Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
550 Forward
Set Voltage
XXX.X Volts
Volts View Modify NA 120.0 100.0 135.0
•Forward Set Voltage for Alternate Configuration 3.
551 Forward
Bandwidth
X.X Volts
Volts View Modify NA 2.0 1.0 6.0
•Forward Bandwidth for Alternate Configuration 3.
552 Forward
Time Delay
XXX Seconds
Seconds View Modify NA 45 5 180
•Forward Time Delay for Alternate Configuration 3.
553 Fwd Line Drop
Comp. Resistance
XX.X Volts
Volts View Modify NA 0.0 -96.0 96.0
•Forward Line Drop Compensation Resistance for Alternate Configuration 3.
554 Fwd Line Drop
Comp. Reactance
XX.X Volts
Volts View Modify NA 0.0 -96.0 96.0
•Forward Line Drop Compensation Reactance for Alternate Configuration 3.
555 Reverse
Set Voltage
XXX.X Volts
Volts View Modify NA 120.0 100.0 135.0
•Reverse Set Voltage for Alternate Configuration 3.
556 Reverse
Bandwidth
X.X Volts
Volts View Modify NA 2.0 1.0 6.0
•Reverse Bandwidth for Alternate Configuration 3.
557 Reverse
Time Delay
XXX Seconds
Seconds View Modify NA 45 5 180
•Reverse Time Delay for Alternate Configuration 3.
558 Rev Line Drop
Comp. Resistance
XX.X Volts
Volts View Modify NA 0.0 -96.0 96.0
•Reverse Line Drop Compensation Resistance for Alternate Configuration 3.
559 Rev Line Drop
Comp. Reactance
XX.X Volts
Volts View Modify NA 0.0 -96.0 96.0
•Reverse Line Drop Compensation Reactance for Alternate Configuration 3.
560 Control
Operating Mode
Sequential
--- View Modify NA Sequential NA NA
•The Control Operating Mode for Alternate Configuration 3.
561 Reverse Sensing
Mode
Locked Forward
--- View Modify NA
Locked
Forward
NA NA
•The Reverse Sensing Mode for Alternate Configuration 3.
92
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
