Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
562 Reverse Current
Sense Threshold
X %
% View Modify NA 1 1 5
•The Reverse Current Sense Threshold for Alternate Configuration 3.
563 Auto Operation
Blocking Status
Normal
--- View Modify NA Normal NA NA
•The Auto Operation Blocking Status for Alternate Configuration 3.
564 Voltage
Reduction Mode
Off
--- View Modify NA Off NA NA
•The Voltage Reduction Mode for Alternate Configuration 3.
565 Local/Digital
Reduction Value
XX.X %
% View Modify NA 0.0 0.0 10.0
•The Local/Digital Reduction Value for Alternate Configuration 3.
566 Remote #1 Value
XX.X %
% View Modify NA 0.0 0.0 10.0
•The Remote latch #1 Voltage Reduction Value for Alternate Configuration 3.
567 Remote #2 Value
XX.X %
% View Modify NA 0.0 0.0 10.0
•The Remote latch #2 Voltage Reduction Value for Alternate Configuration 3.
568 Remote #3 Value
XX.X %
% View Modify NA 0.0 0.0 10.0
•The Remote latch #3 Voltage Reduction Value for Alternate Configuration 3.
569 # of Pulse
Reduction Steps
XX
--- View Modify NA 0 0 10
•The Remote Pulse Voltage Reduction number of steps for Alternate Configuration 3.
570 % of Voltage Red
Per Pulse Step
XX.X %
% View Modify NA 0.0 0.0 10.0
•The Remote Pulse Voltage Reduction % per step for Alternate Configuration 3.
571 Present Voltage
Reduction Step
XX
--- View NA NA NA NA NA
•The Remote Pulse Voltage Reduction Present Voltage Reduction Step for Alternate
Configuration 3.
572 SOFT-ADD-AMP
Limits
Off
--- View Modify NA Off NA NA
•The SOFT-ADD-AMP Limits feature enabled for Alternate Configuration 3.
573 SOFT-ADD-AMP
High Limit
XX
--- View Modify NA 16 NA NA
•The SOFT-ADD-AMP High Limit for Alternate Configuration 3.
93
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
