Eaton HMi VU Series User Manual

HMi VU Series Instruction Leaflet
EATON CORPORATION www.eaton.com 18
MODEL HMIVU06CUNB HMIVU07CUNBE HMIVU08CUNBE HMIVU10WCUNBE
Perpetual Calendar
(RTC)
Built-in
Cooling Method Natural air circulation
Safety Approval CE / UL
Waterproof Degree IP65 / NEMA 4X (indoor use only)
Operation Voltage
(Note 4)
DC +24V (-10% ~
+15%)
Please use
isolated power
supply
DC +24V (-10% ~ +15%)
has built-in isolated power circuit
(Note 3)
Voltage Endurance AC500V for 1 minute (between charging (DC24 terminal) and FG terminals)
Power Consumption
(Note 4)
3.0W 7.68W 7.8W 12W
Backup Battery 3V lithium battery CR2032 x 1
Backup Battery Life Varies based on temperature and conditions. Approximately 3 years or more at 25
o
C.
Operation Temp. 0
o
C ~ 50
o
C
Storage Temp. -20
o
C ~ +60
o
C
Ambient Humidity
10% ~ 90% RH [0 ~ 40
o
C], 10% ~ 55% RH [41 ~ 50
o
C]
Pollution Degree 2
Vibration Resistance
IEC 61131-2 Compliant
5Hz≦f＜9Hz = continuous: 1.75mm / occasional: 3.5mm
9Hz≦f≦150Hz = continuous: 0.5g / occa onal: 1.0g si
X, Y, Z directions for 10 times
Dimensions
(W) x (H) x (D) mm
184 x 144 x 50 184 x 144 x 50
227.1 x 174.1 x
61
272 x 200 x 61
Panel Cutout
(W) x (H) mm
172.4 x 132.4 172.4 x 132.4 219.4 x 166.5 261.3 x 189.3
Weight Approx. 670g Approx. 800g Approx. 1228g Approx.1520g
NOTE
1) The half-life of backlight is defined as original luminance being reduced by 50% when the maximum driving
current is supplied to HMi. The life of LED backlight shown is an estimated value under 25
o
C normal
temperature and humidity conditions.
2) USB Host port can provide up to 5V/ 500mA of power.
3) The withstand voltage of the isolated power circuit is 1500V peak for 1 minute.
4) The value of the power consumption indicates the electrical power consumed by HMi only without
connecting to any peripheral devices. In order to ensure the normal operation, it is recommended to use a
power supply which the capacity is 1.5 ~2 times the value of the power consumption.
5) For further details, please visit the Eaton website www.eaton.com/electrical.

Eaton HMi VU Series Specifications

General

Brand	Eaton
Model	HMi VU Series
Category	Control Unit
Language	English
