HMi VU Series Instruction Leaflet
HMIVU06CUNB (Rear View)
C
G
B
F
A
E
D
A Power Input Terminal E USB Host
B COM2 and COM3
(Note1)
F USB Slave
C COM1 G System Button
D Battery Cover - -
NOTE
1. Refer to the Pin Definition for Communications section for simultaneous use of COM2 and COM3.
