Eaton Magnum PXR Technical Product Guide

23
Technical data and ratings
MAGNUM PXR PRODUCT GUIDE PA013006EN September 2022 www.eaton.com
2
= Narrow
= Standard
= Double narrow
= Double standard
Table 2. Magnum PXR dimensions & weights
Dimension type Narrow frame Standard frame Double narrow frame Double standard frame
Drawout
version -
(D/O in cass
w/terminals)
(mm/in)
Vol (dm
3
/ft
3
) 83.5/2.94 107/3.79 165.7/5.86 225.8/7.98
Width (mm/in) 336/13.2 432 /17.0 667/26.3 909/35.8
Height (mm/in) 524/20.6 524/20.6 524/20.6 524/20.6
Depth - w/o adapters (mm/in) 474/18.7 474/18.7 474/18.7 474/18.7
Adapters are part of Cassette
Bkr + Cass=Total Wgt (lbs) a 108 + 61 = 169 155 + 117 = 272 295 + 106 = 401 343 + 212 = 555
Pole spacing
Distance (mm/in) 95/3.75 127/5.0 95/3.75 127/5.0
Fixed
dimensions
mm/in
Vol (dm
3
/ft
3
) 50.4/1.77 65.1/2.3 109.5/3.86 139.6/4.93
Width (mm/in) 318/12.5 411.5/16.2 633/24.9 823/31.1
Height (mm/in) 426/16.8 426/16.8 426/16.8 426/16.8
Depth - w/o adapters
(mm/in)
371/14.6 371/14.6 415/16.3 415/16.3
Weight - Fixed bkr (lbs) a 95 128 177 276
a
Breaker weights are based on the heaviest breaker configurations. Actual weights may vary depending configuration.
Table 3. 4 pole type
Dimension type Narrow frame Standard frame Double narrow frame Double standard frame
Drawout
version -
(D/O in cass
w/terminals)
(mm/in)
Vol (dm
3
/ft
3
) 83.5/2.94 107/3.79 165.7/5.86 225.8/7.98
Width (mm/in) 432 /17.0 559/22.0 844/33.2 1163/45.8
Height (mm/in) 524/20.6 524/20.6 524/20.6 524/20.6
Depth - w/o adapters (mm/in) 474/18.7 474/18.7 474/18.7 474/18.7
Adapters are part of Cassette
Bkr + Cass=Total Wgt (lbs) a 136 + 70 = 206 194 + 123 = 317 393 + 125 = 518 441 + 266 = 707
Pole spacing
Distance (mm/in) 95/3.75 127/5.0 95/3.75 127/5.0
Fixed
dimensions
mm/in
Vol (dm
3
/ft
3
) 50.4/1.77 65.1/2.3 109.5/3.86 139.6/4.93
Width (mm/in) 413/16.3 538/21.2 824/32.4 1120/44.1
Height (mm/in) 426/16.8 426/16.8 426/16.8 426/16.8
Depth - w/o adapters
(mm/in)
371/14.6 371/14.6 415/16.3 415/16.3
Weight - Fixed bkr (lbs) a 120 160 225 360
a
Breaker weights are based on the heaviest breaker configurations. Actual weights may vary depending configuration.
Table 4. Magnum PXR ANSI breaker family ratings (Class UL1066)
Interrupting
rating (kA)
@ 508 Vac
800 Amp
frame
1200 Amp
frame
1600 Amp
frame
2000 Amp
frame
2500 Amp
frame
3000 Amp
frame
3200 Amp
frame
4000 Amp
frame
5000 Amp
frame
6000 Amp
frame
100
85
65
50
42
ote:N Refer to Table 5 for a detailed ratings table.
