Eaton MMX12 Series Installation Instructions

Emergency On Call Service: Local representative (http://www.moeller.net/address) or +49 (0) 180 5 223822 (de, en) 5/14
03/10 AWA8230-2416
M3
mm
2
AWG mm inch Nm ft-lbs mm
MMX12AA1D7...
MMX12AA2D4...
MMX12AA2D8...
0.2 - 2.5 24 - 12 8 0.31 0.5 - 0.6 0.37 - 0.44 0.6 x 3.5 FS1
MMX32AA1D7...
MMX32AA2D4...
MMX32AA2D8...
MMX34AA1D3...
MMX34AA1D9...
MMX34AA2D4...
0.2 - 2.5 24 - 12 8 0.31 0.5 - 0.6 0.37 - 0.44 0.6 x 3.5 FS1
MMX11AA1D7...
MMX11AA2D4...
MMX11AA2D8...
MMX11AA3D7...
0.2 - 2.5 24 - 12 8 0.31 0.5 - 0.6 0.37 - 0.44 0.6 x 3.5 FS2
MMX12AA3D7...
MMX12AA4D8...
MMX12AA7D0...
0.2 - 2.5 24 - 12 8 0.31 0.5 - 0.6 0.37 - 0.44 0.6 x 3.5 FS2
MMX32AA3D7...
MMX32AA4D8...
MMX32AA7D0...
0.2 - 2.5 24 - 12 8 0.31 0.5 - 0.6 0.37 - 0.44 0.6 x 3.5 FS2
MMX34AA3D3...
MMX34AA4D3...
MMX34AA5D6...
0.2 - 2.5 24 - 12 8 0.31 0.5 - 0.6 0.37 - 0.44 0.6 x 3.5 FS2
MMX11AA4D8... 0.2 - 4 24 - 10 8 0.31 0.5 - 0.6 0.37 - 0.44 0.6 x 3.5 FS3
MMX12AA9D6... 0.2 - 4 24 - 10 8 0.31 0.5 - 0.6 0.37 - 0.44 0.6 x 3.5 FS3
MMX32AA9D6... 0.2 - 4 24 - 10 8 0.31 0.5 - 0.6 0.37 - 0.44 0.6 x 3.5 FS3
MMX34AA7D6...
MMX34AA9D0...
MMX34AA012...
MMX34AA014...
0.2 - 4 24 - 10 8 0.31 0.5 - 0.6 0.37 - 0.44 0.6 x 3.5 FS3
L1
L2/N
e e
U/T1
V/T2
W/T3
L1
L2/N
e e
U/T1
V/T2
W/T3
L3
L3
L2/N
e e
U/T1
V/T2
W/T3
L1
L2/N
e e
U/T1
V/T2
W/T3
L1
L2/N
e e
U/T1
V/T2
W/T3
L3
L1
L2/N
e e
U/T1
V/T2
W/T3
L3 R+ R-
L3
L2/N
U/T1
V/T2
W/T3
e e
L1
L2/N
e e
U/T1
V/T2
W/T3
L1
L2/N
e e
U/T1
V/T2
W/T3
L3
L1
L2/N
e e
U/T1
V/T2
W/T3
L3 R+ R-
