3
①
Parallel card (option) cover
②
EPO (Emergency Power Off)
③
RS232
④
Battery connection socket
⑤
Maintenance switch
⑥
Cable clamp
⑦
Intelligent slot
⑧
Fan
⑨
Input switch
⑩ Terminal block cover
3C-10000F/3C-10000FL
3C-20000FL
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑤
⑥
⑦
⑧
⑨
⑩
①
②
③
