58
Step 5 - Standard application
POWERXL DM1 SERIES ADJUSTABLE FREQUENCY DRIVES PUB53696—August 2020 www.eaton.com
Table 21. System (Cont.).
P13.1.8
Keypad parameter lock
ID 625
Minimum value:
N.A.
Maximum value:
N.A.
Default value:
0
Options:
0 = Change enable; or
1 = Change disable.
Description:
This function allows the user to prohibit changes to the parameters. If the parameter lock is activated, the text “locked” will appear on
the display if you try to edit a parameter value.
Note: This function does not prevent unauthorized editing of parameter values.
P13.1.9
Start-up Wizard
ID 626
Minimum value:
N.A.
Maximum value:
N.A.
Default value:
0
Options:
0 = Enabled.
1 = Disabled.
Description:
The Start-up Wizard facilitates commissioning the DM1 PRO. If selected “Enable”, the Start-up Wizard prompts the operator for
the application desired and then advances parameters through the start-up parameter list/Application Mini wizard in keypad. After
completion, it allows the user to go to the main menu or default page and this parameter is set to “Disabled”. The Start-up Wizard is
always enabled for the initial power up of the DM1 PRO. By setting this parameter to “Disable” without going through the Start-up
Wizard, it will not cause it to be active on start-up. If user goes into Start-up Wizard after completion, or defaults drive, the Start-up
Wizard will be “Enabled”.
P13.2 - Keypad.
P13.2.4
Timeout time
ID 629
Minimum value:
1 s
Maximum value:
65.535 s.
Default value:
30 s
Description:
The timeout time setting defines the time after which the keypad display returns to the Default Page.
Note: If the default page value is 0, the timeout time setting has no effect.
P13.2.5
Contrast adjust
ID 630
Minimum value:
5
Maximum value:
18
Default value:
12
Description:
If the remote keypad display is not clear, you can adjust the keypad contrast with this parameter.
P13.2.6
Backlight time
ID 631
Minimum value:
1 min.
Maximum value:
65,535 min.
Default value:
10 min.
Description:
This parameter determines how long the backlight stays on before going out.
P13.2.7
Fan control
ID 632
Minimum value:
N.A.
Maximum value:
N.A.
Default value:
2
Options:
0 = Continuous - fan runs continuously.
1 = Temperature - based on the temperature of the unit. The fan is switched on automatically when the heat sink temperature reaches
60°C (140°F). The fan receives a stop command when the heat sink temperature falls to 55°C (131°F). The fan runs for about a
minute
after receiving the stop command or switching on the power, as well as after changing the value from “Continuous” to
“Temperature”.
2 = Run follow - after power up, the fan is stopped until the run command is given and then fan runs continuously. This is mainly made
for common DC-bus systems to prevent cooling fans to load charging resistors on power up moment.
Description:
This function allows you to control the DM1 PRO’s cooling fan.
P13.4 - Version information.
P13.4.1
Keypad software version
ID 640
Minimum value:
N.A.
Maximum value:
N.A.
Default value:
N.A.
Description:
Keypad firmware version.
P13.4.2
Motor control software version
ID 642
Minimum value:
N.A.
Maximum value:
N.A.
Default value:
N.A.
Description:
DSP/motor control software version.
