MAU-00075 AB
6
ENGLISH
Troubleshooting
◗ The battery backup outlets
8
are not supplied with power.
◗ The connected devices are not
supplied when AC power fails.
◗ AC power is available, but the
UPS operates on battery power.
◗ The filtered outlets
7
are not
supplied.
◗ Green button
11
flashes
frequently and audio alarm beeps
every 5 secondes.
◗ Green button
11
flashes
frequently and audio alarm is
continuous.
◗ Red LED
10
is on and the
audio alarm beeps every 30
seconds.
◗ Green LED
9
is off and the
filtered outlets
7
are supplied.
◗ The telephone line is disturbed
or modem access is not possible.
◗ Red LED
10
is ON.
Problem Diagnostic Solution
◗ Button
11
is not pressed.
◗ The devices are not connected to
the battery backup outlets
8
.
◗ Circuit breaker
12
has been tripped
by an overload on the UPS output.
◗ The wall outlet is not supplied.
◗ Circuit breaker
12
has been tripped
by an overload on the UPS output.
◗ The UPS frequently operates on
battery power because the AC power
source is of poor quality.
◗ The UPS battery backup outlets
8
are overloaded.
◗ A fault has occurred on the UPS.
The battery backup outlets
8
are no
longer supplied.
◗ Surge protection is no longer
provided.
◗ Surge protection on the telephone
line is no longer provided.
◗ The battery has reached the end of
its service life.
◗ Press button
11
and check that it
turns green.
◗ Connect the devices to the battery
backup outlets
8
.
◗ Disconnect excess equipment and
reset the circuit breaker
12
by pressing
the corresponding button.
◗ Supply power to the wall outlet.
◗ Disconnect excess equipment and
reset the circuit breaker
12
by pressing
the corresponding button.
◗ Have the electrical installation
checked by a professional or use
another wall outlet.
◗ Disconnect excess equipment
connected to the battery backup outlets
8
.
◗ Call after-sales support.
◗ Call after-sales support.
◗ Disconnect the telephone line from
the wall outlet.
◗ Call after-sales support.
◗ Have the battery replaced.
1
2
3
4
5
6
7
8
9
10
Advanced customizing of your UPS:
Sensitivity to variations of the AC power supply
◗ Only to be used if frequent switching to the UPS battery
due to large variations in the AC supply voltage.
◗ Accessing the programming mode: with the device
switched off, press button
11
for 6 s and release it once
LEDs
10
11
9
have come on.
◗ Display of the 3 possible voltage ranges according to the
status of LEDs
10
and
11
:
Audio alarm
◗ Possibility of deactivating the audio alarm when the UPS
is operating on the battery.
◗ Accessing the programming mode: with the device
switched off, press button
11
for 11 s and release it once
the audio alarm sounds.
◗ Display of the 2 possible audio alarm modes:
Normal mode
(factory
configuration):
AC supply
between 184V
and 264V
Low range
mode:
AC supply
between 160V
and 264V
Low and high
range mode:
AC supply
between 160V
and 284V
◗ Memorizing the mode: 10 s after the last press of the
button.
◗ Memorizing the mode: 10 s after the last press of the
button.
Normal mode (factory
configuration):
the UPS emits a beep every
10 s when operating on its
battery.
Silent mode:
the UPS emits a single
beep when switching to
battery operation and then
remains silent.
10 11
9
10 11
9
10 = ON 11 = OFF 10 = OFF 11 = ON10 = ON 11 = ON
10 11
9
Normal mode
activated:
Buzzer emits long
beep.
Silent mode
activated:
Buzzer emits
short beep.
Change from one mode to another by
successively pressing button
11
.
Change from one mode to another by
successively pressing button
11
.
