Eaton REC Series - Rack Earth Bonding Procedures

11
©2015 Eaton Corporation
All rights reserved
REC Series Enclosure Installation Guide _issue 4
Installation Guide
9. RACK EARTH BONDING
Earth Kit Components (note; not all components used in every application);
ITEM
REF
DESCRIPTION LENGTH QUANTITY IMAGE
1 M6 x 25mm Zinc Plated Setscrew 25mm 4
2 M6 Shake proof Washer 8
3 M6 x 12mm Setscrew (4mm Allen) 12mm 4
4 M6 Plain Washers 24
5 M6 Serrated Hexagonal Flange Nut 18
6 Earth Lead 500mm 2
7 Earth Lead 350mm 8
TOOLS REQUIRED:
 SPANNER (WRENCH) - 10mm (x2)
 ALLEN KEY - 4mm
