PTO Configurations
Heavy-Duty Manual Transmission - RT Series
Model 8-Bolt Gear Info. 6-Bolt Gear Info. Thru-
shaft
Int.
Spline
Info.
Ext. Aux.
Counter-
shaft PTO
Ext.
Spline
Info.
% of
Engine
Speed
Transmission
Torque Limit for
PTO use (lb-ft)
RT-6609A Yes
33T 6.0P,
20DE
G A
Yes
33T 6.0P,
20DEG A
N/A N/A N/A N/A 72
350
RT-8709B Yes
47T 6.0P,
20
DEG PA
Yes
4
45T 6.0P,
20DEG PA
Lower
Left
32T 0.5P,
30DEG PA
N/A N/A 70
500
6
RT-11709H Yes
47T 6.0P,
20
DEG PA
Yes
4
45T 6.0P,
20DEG PA
N/A N/A N/A N/A 70
350
5
RT-12709H Yes
47T 6.0P,
20
DEG PA
Yes
4
45T 6.0P,
20DEG PA
N/A N/A N/A N/A 70
RT-13709H Yes
47T 6.0P,
20
DEG PA
Yes
4
45T 6.0P,
20DEG PA
N/A N/A N/A N/A 70
RT-14709H Yes
47T 6.0P,
20
DEG PA
Yes
4
45T 6.0P,
20DEG PA
N/A N/A N/A N/A 70
RTX-11609B Yes
47T 6.0P,
20
DEG PA
Yes
4
45T 6.0P,
20DEG PA
N/A N/A N/A N/A 79
RTX-12609B Yes
47T 6.0P,
20
DEG PA
Yes
4
45T 6.0P,
20DEG PA
Lower
Left
32T 0.5P,
30DEG PA
N/A N/A 79
RTX-13609B Yes
47T 6.0P,
20
DEG PA
Yes
4
45T 6.0P,
20DEG PA
Lower
Left
32T 0.5P,
30DEG PA
N/A N/A 79
RTX-14609B Yes
47T 6.0P,
20
DEG PA
Yes
4
45T 6.0P,
20DEG PA
Lower
Left
32T 0.5P,
30DEG PA
N/A N/A 79
RTX-16709B Yes
47T 6.0P,
20
DEG PA
Yes
4
45T 6.0P,
20DEG PA
Lower
Left
32T 0.5P,
30DEG PA
N/A N/A 79
T-14607A Yes
47T 6.0P,
20
DEG PA
Yes
45T 6.0P,
20DEG PA
N/A N/A N/A N/A 51
T-14607B Yes
47T 6.0P,
20
DEG PA
Yes
45T 6.0P,
20DEG PA
N/A N/A N/A N/A 51
TX-14607B Yes
47T 6.0P,
20
DEG PA
Yes
45T 6.0P,
20DEG PA
N/A N/A N/A N/A 69
Note: (4) - 6-bolt PTO will interfere with front mount oil filter. Rear or remote mount oil filter must be utilized.
Note: (5) - Transmission
may be ordered with heavy-duty input bearing (4301417) to allow a combined PTO output of 500 lb-ft
(continuous) and 750 lb-ft (intermittent) torque.
Note: (6) - Intermittent torque
of up to 750 lb-ft at the countershaft is permitted for 5 minutes of each 15 minute PTO duty cycle.
