Cable Connector (Metri-Pack) - 3-Way 12124685
Seal Range (mm) / (in) Contact Size Description Cable Diameter MIn
(mm²)
Cable Diameter Max
(mm²)
TXL GXL SXL
4.40 - 5.15 /.173 -.202 10 Power (ECA) 4.40 5.15 NR NR 10
Back Shell (Deutsch) *Low Profile Back Shell (Deutsch)
Part Number 0528-004-3805 0528-005-3805
Conduit / OEM Packard Packard
Conduit P/N *(R-69246 round) Convoluted Tubing; Size
13 mm [.500]; 125° C or higher temperature
rating
(R-72506 profile) *(R-69246 round) Convo-
luted Tubing; Size 13 mm [.500]; 125° C or
higher temperature rating
29
Cable Configuration
Note: (*) Eaton
®
recommended component.
Recommended Bend Radius (6 X Hardness Diameter):
Inch Metric (mm)
Diameter Bend Radius Diameter Bend Radius
3/16 (0.188) 1.1 5 29
1/4 (0.250) 1.5 6 38
3/8 (0.375) 2.3 10 57
1/2 (0.500) 3.0 13 76
5/8 (0.625) 3.8 16 95
3/4 (0.750) 4.5 19 114
1/1 (1.000) 6.0 25 152
Contact Lubrication
Manufacturer: Nye Lubricants
Material: NyoGel 760G
Eaton
®
Part Number: 5564527 (service, 2 CC Foil), 5564528 (service, 30 CC Syringe)
Bosch Part Number: N28 FT7020-005
Ford: WSB-M1C239-A
GM: 9986087
DaimlerChrysler: MS-9469
