ePTO (HCM Analog Controlled)
Description From Pin# To Pin# AWG
PTO Signal HCM 18 ePTO 18
PTO Power Plus HCM 34 ePTO 18
PTO Power Minus HCM 6 ePTO 18
ePTO (HCM J1939 Controlled)
Description From Pin# To Pin# AWG
J1939 Low (CAN) HCM 2 J1939 Backbone 2 18
J1939 High (CAN) HCM 3 J1939 Backbone 3 18
mPTO (HCM Controlled)
Description From Pin# To Pin# AWG
PTO Signal HCM 19 mPTO PTO Grnd Switch 18
43
PTO Interface
