Eaton SL7 Series User Manual

IP66
-30°C .. +60°C
(-22°F .. +140°F)
02/13 IL047003ZU
2/3
Emergency On Call Service: Local representative (www.eaton.eu/aftersales) or +49 (0) 180 5 223822 (de, en)
1
1
2
6mm
(0.24 in)
0,2 - 2,5mm²
(24 - 14 AWG)
3
2
54mm
54mm
(2-1/8)
(2-1/8)
2 Nm
(18 lb-in.)
4 x M5
SL7-CB-...
(UL type 4, 4X, 13)
SL7-CB-IMS
(UL type 4, 4X, 13)
52mm
(2-1/64)
2 Nm
(18 lb-in.)
2 x M5
52mm
2 Nm
(18 lb-in.)
2 x M5
(2-1/64)
SL7-CB-IMH
(UL type 1)
85mm
85mm
2 Nm
(18 lb-in.)
4 x M5
(3-21/64)
(3-21/64)
SL7-CB-EMH
(UL type 4, 4X, 13)
70mm
(2-3/4)
2 Nm
(18 lb-in.)
2 x M5
SL7-CB-FW
(UL type 4, 4X, 13)
82mm
31mm
(3-1/4)
(1-1/4)
2 Nm
(18 lb-in.)
4 x M5
SL7-CB-D
(UL type 4, 4X, 13)
SL7-CB-T-...
(UL type 4, 4X, 13)
Ø21mm
20 Nm
(15 lb-ft.)
(7/8)
2
1
0
5
4
3
1
2
3
4
5
012345
SL7-CB-IMH
3
4
CLICK
1
2
3
max. 5
max. 5
0,8 x 5,5
0,4 x 2,5
