Turning the disconnector on:
Press the on button to turn the disconnector on.
After turning the disconnector on:
Earthing disconnector is on, disconnector is on, key
disconnector safety lock is open.
Turning the earthing disconnector off:
Place the assembly lever into the earthing disconnector
assembly housing and turn off the earthing disconnector
by rotating in arrow direction.
If the cell is an input cell:
Check if the energy is broken from previous center before
turning the earthing disconnector off.
After turning off the earthing disconnector:
Earthing disconnector is off, disconnector is on, Now the
cell front cover may be removed.
