EBARA 3U - Pump Specifications

EBARA End Suction Centrifugal 3U / 3UB
Operating, Installation, and Maintenance
EBARA Fluid Handling
www.pumpsebara.com 6
(t) 803 327-5005 • (f) 803 327-5097 rev. 02/09
Standard Optional
Size
Suction 3U32 – 2'' ANSI Equivalent Companion Flange kit
(150 lb. ANSI R.F. equivalent) 3U40 – 2
1
/2
'' ANSI Equivalent 150 Lb. ANSI, Female NPT
3U50 – 2
1
/2'' ANSI Equivalent
3UB65 – 3'' ANSI Equivalent
Discharge 3U32 – 1
1
/4'' ANSI Equivalent
(150 lb. ANSI R.F. equivalent) 3U40 – 1
1
/
2'' ANSI Equivalent
3U50 – 2'' ANSI Equivalent
3UB65 – 2
1
/2'' ANSI Equivalent
Range of HP 3U – 3 HP to 15 HP
3UB – 7
1
/2 HP to 30 HP
Range of Performance
Capacity 13 to 750 GPM at 3450 RPM
Head 33 to 250 feet at 3450 RPM
Liquid handled
Type of liquid Clean water
Temperature 212°F (100°C) Max. 250°F (121°C) with optional
high temperature seal
Max. working pressure 230 PSI (15 Bar)
Materials 3U 3UB
Casing 304L Stainless Steel 304L Stainless Steel
Impeller (closed type) 304L Stainless Steel Bronze
Stainless steel option for 3UB models
Shaft Sleeve 304L Stainless Steel 304L Stainless Steel
Bracket Cast iron Cast iron
Shaft Seal
Mechanical Seal – Type 21
Seal Material Carbon/Ceramic/Viton Consult factory for additional
Carbon/Ceramic/Buna optional seal availability
Hot water – Carbon/Ni-Resist/Viton, 250°F (121°C) max.
Direction of Rotation Clockwise when viewed from motor end
Motor
Type NEMA JM, TC, TSC Frame
Speed 60 Hz, 3450 RPM (2 poles) 4 pole – consult factory as noted
Bearing Ball Bearing
Single Phase TEFC – 3 HP
ODP – 3 HP to 10 HP
Three Phase TEFC – 3 HP to 30 HP Explosion proof – consult factory
ODP – 3 HP to 30 HP for availability
208-230/460V Washdown duty – consult factory
Motor Protection Overload protection must be provided for availability
Standard Accessories Suction and Discharge Flange Gasket
Motor support
Specifications
