EBARA 3U - Sectional Views; Sectional View - Type 1

EBARA End Suction Centrifugal 3U / 3UB
Operating, Installation, and Maintenance
EBARA Fluid Handling
www.pumpsebara.com 7
(t) 803 327-5005 • (f) 803 327-5097 rev. 02/09
Sectional view – 3U / 3UB Type 1
001
011
018
021
021
039
041
111
115
117-1
117-2
117-3
125
160
212
800
Casing
Casing cover
Bracket
Impeller (3U)
Impeller (3UB)
Key
Shaft sleeve
Mechanical seal
O-Ring
Gasket
Gasket
Gasket
Impeller Bolt
Motor support (not shown)
Plug
Motor
Suction Flange Gasket
Discharge Flange Gasket
304L Stainless
304L Stainless
Cast Iron
304L Stainless
Bronze
304L Stainless
304L Stainless
–
Viton
Nylon
Nylon
Nylon
304L Stainless
Steel
304L Stainless
–
Viton
Viton
1
1
1
1
1
1
1
1
1
1
1
1
1
1 set
1
1
1
1
Part No. Part Name Material No. for 1 Unit
212
001
125
021
115
111
011
117-3
041
117-2
129
135-1
018
039
800
117-1
