EBARA TH Series - Page 15

15
Rev10/2018
Operating, Installation, and Maintenance
THD Assembly Instruction (Continued)
Pump Assembly – THD Closed Coupled






Step 6

Placethecasingcover(item011)onbracket(item
803).Usehexheadbolts(item120‐2).

Step 7




Insertthekey(item039)intomotorshaft.
Step 8 - A

Inserttheimpellerwearring(item025)onthe
impeller(item021),usingasoftfacehammer.

Step 8 - B

Placetheimpeller(item021)onmotorshaftusing
theimpellerbolt(item275)andbushing(item080).

Step 9

Insertthecasingwearring,(item107)oncasing
(item001)usingasoftfacehammer.

