EBS BZ-1 - Specifications

User’s Manual
- 10 -
Specifications
BZ-1 Bouzouki Preamplifier:
Inputs:
Input Impedance 308KΩ
Effects Return Impedance 13KΩ
Outputs:
Output Impedance 600Ω Balanced
Stage Line Output Impedance 600Ω Balanced
FOH DI Line Output Impedance 600Ω Balanced
Effects Send Impedance 600Ω
Power Supply:
Mains Voltage 230VAC / 50Hz – 60HZ
Power consumption 15W
Physical/Weight:
Dimensions: 482mm x 160mm x 44mm
Weight 2.5Kg
CE mark for European harmonised standards
The CE mark means the product conforms to EMC Directive (EN 55103-1 & EN 55103-2) and the Low Voltage Directive in the EU.
PU-2 Bouzouki Pickup
Output Impedance 1KΩ Recommended load ≥ 10KΩ
Max Output 1.3V Peak
Battery 3V CR2 Lithium
Battery Life 2000 Hours
Dimensions 82mm x 42mm x 32mm
Weight 79g without battery (90g with battery)
CE mark for European harmonised standards
The CE mark means the product conforms to EMC Directive (EN 55103-1 & EN 55103-2).
