USERS MANUAL
EBS DYNAVERB - STUDIO EDITION
www.ebssweden. com
POWER OPTIONS
DC POWER ADAPTOR For environmental reasons,
we recommend the use of a DC Power
Supply, such as the EBS AD-9+. The EBS
UniChorus Studio Edition handles 9-12
V DC, and require a 2.1 mm pin center
negative type of connector.
BATTERY The DynaVerb pedal can run on
battery (not included), but since it need quite
a lot power – we strongly recommend to use
it with a power supply for constant use.
To place a battery in the pedal follow
these steps.
1) Remove the four screws holding
the bottom plate.
2) Carefully remove the bottom plate.
3) Place a 9V alkaline type; 6LR61 in
the battery holder.
4) Gently place back the bottom plate.
Attach the four mounting screws using
To Next Page
