USERS MANUAL
EBS MULTICOMP - GUITAR EDITION
www.ebssweden.com
TECHNICAL SPECIFICATIONS EBS MULTICOMP Guitar Edition
Nominal Input Level -10 or -4 dBv
Input Impedance 700 kohms
Bandwidth +0/-3 dB 20 - 20k Hz
Gain Range 0 - 15 dB
Compressor Ratio min/max 1:1 - 5:1
Threshold (adjustable inside) -25 - +6 dB
Attack Time (80%) <7 ms
Release Time (80%) typ. 70 ms
Dimensions Width 2.8" (70 mm)
Height 4.5" (115 mm)
Depth 1.4" (35 mm)
Weight 400g (0.88 lb.)
Power Requirements 9 - 12 V DC Regulated, 35 mA max.
Protected against accidental over voltage up to 18 V.
Specifications are subject to change without notice.
If you did not find the answer in this manual, please contact
EBS at support@ebssweden.com
