USERS MANUAL
EBS MULTIDRIVE - STUDIO EDITION
www.ebssweden. com
POWER OPTIONS
DC POWER ADAPTOR For environmental reasons,
we recommend the use of a DC Power
Supply, such as the EBS AD-9+. The EBS
MultiDrive Studio Edition handles 9-12
V DC, and require a 2.1 mm pin center
negative type of connector.
BATTERY This pedal can run on battery (not
included). To place a battery in the pedal
follow these steps.
1) Remove the four screws holding
the bottom plate.
2) Carefully remove the bottom plate.
3) Place a 9V alkaline type; 6LR61 in
the battery holder.
4) Gently place back the bottom plate.
Attach the four mounting screws using
moderate tension.
