USERS MANUAL
EBS STANLEY CLARKE PREAMP
www.ebssweden.com
ELECTRET FUNCTION
This switch should be set to
OFF at all times, except when
using an Electret pickup on
the A channel (INPUT).
BASS is a 'shelving' type
filter with a wide gain
range. Identical on both
channels.
MID. These two knobs works in conjunction. Use the left
control to pick a frequency. Use the right control to boost
or cut the gain in the range of the chosen frequency. The
MID-controls are identical on both channels.
PHASE. This switch inverts
the phase of the A channel
when needed.
MUTE FOOT SWITCH. Mutes the balanced
outputs and the master output.
Fx Send is not affected by this function.
MASTER controls the volume on the Output jack.
The balanced output (XLR) is not affected by the
setting of this knob.
CHANNEL CONTROLS, SWITCHES & OUTPUTS
