USERS MANUAL
EBS STANLEY CLARKE PREAMP
www.ebssweden.comwww.ebssweden.com
TECHNICAL SPECIFICATIONS
Common Features:
Effects Loop: Loop Signal Level -10 dBv (nominal)
Gain Unit y (1:1)
Output Impedance 2 kohms
Input Impedance 100 kohms
Modes Serial or Parallel
Phones Out: Recommended Imp. 32 - 200 ohms
Aux Input: Input Impedance 20 kohms
Nominal Level -10 dBv
Output: Output Impedance <1 kohms
Signal Level 0 dBv (nominal)
Balanced Output: Output Level -20dBv (nominal)
XLR Connections 1-GND, 2-Hot, 3-Cold
Options Gnd Lift, SPKR Sim
Balanced Input (Channel B): Input Level -30dBv (nominal)
XLR Connections 1-GND, 2-Hot, 3-Cold
48V Phantom Yes
Auxiliary Info:
Power Requirements Idle 500mA @9V
max 800mA @9V
(with headphones at
max output level)
Dimensions (WxDxH): max 168 x 124 x 53 mm /
6.6” x 4.9” x 2.1”
Weight: 660 g (1.5 lbs.)
Specifications are subject to change without notice.
