Ebyte E104-BT11 User Manual

Chengdu Ebyte Electronic Technology Co., Ltd E104-BT11 User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co.,Ltd
13
of Ebyte.
Length
（
1 byte HEX
）
Payload (N byte HEX)
N
Parameter configuration
Transparent transmission
5.4.1 Parameter configuration
The configuration data is used to read and write various parameter information of the module and the network access operation
of the device. The format is as follows
Instruction（1 byte）
Operation code（1 byte）
Data（N byte）
TX
0xC0
0~255
request data
RX
0x40
0~255
response data
Note: The correct configuration operation will get the corresponding response data. If the configuration is incorrect, the error
code will be returned as follows
Error code
Description
0xFF
Invalid parameter
0xFE
Operation busy
0xFD
Invalid command
0xFC
No network equipment
0xFB
Failed to get parameters
0xFA
Failed to assign netkey
0xF9
Binding Appkey timeout
0xF8
Failed to bind Appkey
0XF7
The last networking is not over
0x01
No network created (no NETKEY)
0x02
No group created (no APPKEY)
0x03
This operation cannot be performed in the current state
0x04
PB-ADV configuration error
0x05
PB-GATT configuration error
0x06
Startup configuration error
0x07
0x08
0x09
0x0a
0x0b
0x0c
5.4.1.1 NetKey configuration
Network key for the network ID assigned by the provisioner in the process, in the following format.
