Ebyte E104-BT11 User Manual

Chengdu Ebyte Electronic Technology Co., Ltd E104-BT11 User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co.,Ltd
16
Operation
code
Parameter (1 Byte)
Request
0x09
With
parameter
bit
7 ～ 4
3
2
1
0
0：disable;1：
enable
reserved
LPN（low power）
Relay
Proxy
Friend
No parameter
Response
0x09
MAC address
Network address
Element quantity
11 22 33 44 55
00 04
03
For
example,
With parameter request
（enable friend, proxy, relay）
03 C0 09 03
No parameter requests
（all disable）
02 c0 09
response
0B 40 09 11 22 33 44 55 66 00 04 03
Remark
1. This directive only applies to BT11-G;
2. LPN roles cannot be relayed and Friend coexists. Once set to LPN, the relay and Friend roles are automatically
disabled.
5.4.1.9 Delete node
Operation
code
Parameter (2 Byte)
Request
0x0A
The address of the node to be deleted
Response
0x0A
The address of the node to be deleted
For example,
Request
04 C0 0A 00 01
Response
04 40 0A 00 01
Remark
1. This instruction is only applicable to BT11-G;
2. This instruction only deletes the local data of BT11-G, it will not affect the node at this address;
5.4.1.10 Get node network address
Operation
code
Parameter
Request
0x0B
N/A
Response
0x0B
Prov
addr
0, no network configuration; 1 has
configured
the main element address
For example,
Request
02 C0 0B
Response
05 40 0B 00 00 04
Remark
1. This instruction is only applicable to E104-BT11 configuration operation;
2. The unicast address of the main element of the E104-BT11 device in the current network is returned;
