Ebyte NB144 User Manual

Chengdu Ebyte Electronic Technology Co., Ltd. NB144 User Manual
Copyright ©2012，Chengdu Ebyte Electronic Technology Co., Ltd.
5
2 Quick Start
2.1 Hardware List
1.laptop with RJ45 network port.
2.NB1 44 serial port server.
3.One DC12V 1A power adapter .
4.a network cable.
5.One USB to RS485 serial cable.
6.The specific preparation of hardware equipment is shown in the following:
PC
Ethernet cable
NB144
DC 12V1A
USB to RS45
wires
[Note] This chapter only uses one RS485 interface for demonstration, and the other interfaces can use the
corresponding USB converter.
