Ebyte NB144 User Manual

Chengdu Ebyte Electronic Technology Co., Ltd. NB144 User Manual
Copyright ©2012，Chengdu Ebyte Electronic Technology Co., Ltd.
7
2.3.2 Device parameter configuration
In order to enable users to quickly have a simple understanding of the serial server, we use the default parameters
of the serial server to conduct data transparent transmission tests. The default parameters of N B1 44 serial port
server equipment are shown in the table below.
project
default parameters
IP address
192.168.3.7
subnet mask
255.255.255.0
gateway
192.168.3.1
Channel 1 working mode
TCP_SERVER
Local port for channel 1
8 001
Serial baud rate
1 15200
Serial parameters
NONE/8/1/NONE
Make sure that the computer IP and serial server IP are in the same network segment and cannot conflict. The
inspection method is shown in the figure below.
