EC-80320 User’s Manual
- 43 -
GS k Print bar code
Format: ASCII: GS k m d1..dk NUL
Decimal: 29 107 m d1..dk 0
Hex: 1D 6B m d1..dk 00
* ASCII: GS k m n d1..dn
Decimal: 29 107 m n d1..dn
Hex: 1D 6B m n d1..dn
*when m>64
m Bar code
type
Amount of
data
The range of
k
character Character code
0 UPC-A Fixed 11<=k<=12 0~9 48<=d<=57
1 UPC-E Fixed 11<=k<=12 0~9 48<=d<=57
2 EAN13 Fixed 12<=k<=13 0~9 48<=d<=57
3 EAN8 Fixed 7<=k<=8 0~9 48<=d<=57
4 CODE39 Can be
changed
1<=k 0~9,A~Z,SP,
$,%,+,-,.,/
*(stat, stop)
48<=d<=57,48<=d<=57,
d=32,36,37,43,45,46,
47. d=42(stat, stop)
*65 UPC-A Fixed 11<=n<=12 0~9 48<=d<=57
*66 UPC-E Fixed 11<=n<=12 0~9 48<=d<=57
*67 EAN13 Fixed 12<=n<=13 0~9 48<=d<=57
*68 EAN8 Fixed 7<=n<=8 0~9 48<=d<=57
*69
CODE39 Can be
changed
1<=n<255 0~9,A~Z,SP,
$,%,+,-,.,/
*(star, stop)
48<=d<=57,48<=d<=57,
d=32,36,37,43,45,46,
47. d=42(stat character)
*70
ITF
Can be
changed
1<=n<255
(Even)
0~9 48<=d<=57
*71
CODABAR Can be
changed
1<=n<255 0～9,A～
D,$,+,-,.,/,:
48≤d≤57,65≤d≤68,
36,43,45,46,47,58
*73
CODE128 Can be
changed
2<=n<255 NUL~SP(7F
H)
0<=d<=127
GS v 0 Print raster bit image
Format: ASCII: GS v 0 m xL xH yL yH d1…dk
Decimal: 29 118 48 m xL xH yL yH d1…dk
Hex: 1D 76 30 m xL xH yL yH d1…dk
Description:
Print a raster bit image using the mode specified by m as follows.
m=0, 48: normal; m=1, 49: double width; m=2, 50: double height; m=3, 51: quadruple.
XL,xH,yL,yH=0~255;
XL,xH specifies (xL+xH*256) bytes in horizontal direction for the bit image;
YL,yH specifies (yL+yH*256) dots in vertical direction for the image.
k= (xL+xH*256)*(yL+yH*256) indicates the number of bit image data.
GS w Set barcode width
Format: ASCII: GS w n
Decimal: 29 119 n
Hex: 1D 77 n
Description:
Set the horizontal size of barcode.
2<=n<=6.
