EC-80320 User’s Manual
- 42 -
GS L Set left margin
Format: ASCII: GS L nL nH
Decimal: 29 76 nL nH
Hex: 1D 4C nL nH
Description:
Set the left margin to (nL+nH*256)*(horizontal or vertical motion unit); nL, nH=0～255.
Horizontal or vertical motion unit is specified by GS P command.
GS P Set horizontal or vertical motion unit
Format: ASCII: GS P x y
Decimal: 29 80 x y
Hex: 1D 50 x y
Description:
Set the horizontal and vertical unit to 1/x inch and 1/y inch.
When x or y=0, the default horizontal or vertical unit is selected.
GS V Select cut mode and cut paper
Format: ASCII: GS V m (n)
Decimal: 29 86 m (n)
Hex: 1D 56 m (n)
Description: (There is only one cut mode can be selected if the cutter can only realize one cut
type.)
m=0，48;No n parameter, Executes a full cut.
m=1，49;No n parameter, Executes a partial cut (with one point left in the middle).
m=6，n=0~255;Feed paper to n*(horizontal or vertical motion unit) and executes a full cut.
m=66，n=0~255;Feed paper to n*(horizontal or vertical motion unit) and executes a partial cut.
GS W Set print area width
Format: ASCII: GS W nL nH
Decimal: 29 87 nL nH
Hex: 1D 57 nL nH
Description:
Set the print area width to (nL+nH*256)* (horizontal or vertical motion unit), nL, nH=0～255.
Horizontal or vertical motion units are specified by GS P.
GS f Select the HRI character font
Format: ASCII: GS h n
Decimal: 29 102 n
Hex: 1D 66 n
Description:
Selects the HRI character when printing a bar code, using n as follows:
n=0,48；Selects character A (12*24)
n=1,49；Selects character B (8*16)
GS h Set bar code height
Format: ASCII: GS h n
Decimal: 29 104 n
Hex: 1D 68 n
Description:
Set the height of the bar code to n dots.
n=0～255.
