ECD DO82 Instructional Manual

HYDRA-DS NO
3
-N Page 48
Sensor Abbreviated Name
ASCII bytes 4 and 5
1
16 bit
Integer
RW
Y
88
58
Sensor Abbreviated Name
ASCII bytes 6 and 7
1
16 bit
Integer
RW
Y
89
59
Initiate S80 Storage
Signals the user has completed entering the data and
wants it stored. Write any value.
1
16 bit
Integer
W
90
5A
Cal log number to read
Cal log number to read (0 - Cal Log 1, 1 - Cal Log 2, 2 -
Cal Log 3)
1
16 bit
Integer
RW
91
5B
S80 Cal Log slope (hi word)
(bytes 3 and 2)
2
32 bit
Floating
Point
R
92
5C
S80 Cal Log slope (lo word)
(bytes 1 and 0)
93
5D
S80 Cal Log offset (hi word)
(bytes 3 and 2)
2
32 bit
Floating
Point
R
94
5E
S80 Cal Log offset (lo word)
(bytes 1 and 0)
95
5F
S80 Cal Log offset Voltage
(hi word)
(bytes 3 and 2)
2
32 bit
Floating
Point
R
96
60
S80 Cal Log offset Voltage
(lo word)
(bytes 1 and 0)
97
61
Fault Status
Bit #
Bit meaning
0
Memory Error, either a Program Flash, RAM or NVM RAM checksum error has occurred
1
Input Voltage Out Of Tolerance
2
The On Board +12V is Out of Tolerance
3
The On Board +3.3V is Out of Tolerance
4
The Transmitter has lost communication link with the Sensor
5
There is no Sensor connected
6
Sensor Calibration Failed
7
Relay 1 on-time expired
8
Relay 2 on-time expired
9
Relay 3 on-time expired
10
Sentinel Error (useable life has expired)
11
Sentinel Poisoned
12
Membrane Error
13
NU
14
NU
15
NU
WARNING STATUS
Bit #
Bit meaning
0
The Sensor has changed from previously connect Sensor
1
Not Used (NU)
2
NU
3
NU
4
NU
5
NU
6
NU
7
NU
8
NU
9
NU
10
NU
11
NU
12
NU
13
NU
14
NU
15
NU
