EXPLODED DRAWING CHART
NO.
Description
Specification
QTY
1
Bottom frame 1
2
Main frame 1
3
Left upright 1
4
Right upright 1
5
Incline frame 1
6
Console neck frame 1
7
Handlebar frame 1
9
Ezfit linking parts 1
10
Handle grip 1
11
Allen truss head half thread bolt half thread M8×50×20 2
12
Hex lock nut M8 12
13
Allen half thread bolt M12×Φ14×35×19 2
14
Allen truss head half thread bolt M8×35×20 4
15
Allen socket head full thread bolt M8×75 2
16
Allen socket head full thread bolt M8×60 1
17
Allen flat head full thread bolt M6×25 10
18
Phillips truss head full thread bolt M5×10 4
19
Phillips truss head full thread bolt M4×10 10
20
Phillips flat head self-tapping screw ST4×15 18
21
Phillips truss head self-tapping screw ST4×16 10
22
Phillips flat head self-tapping screw ST3×10 2
23
Allen truss head half thread bolt M8×40×20 2
24
Hex lock nut M10 3
25
Allen truss head half thread bolt M10×65×20 1
26
Allen truss head full thread bolt M8×25 4
27
Allen socket head full thread bolt M8×35 8
28
Phillips truss head self-tapping screw ST4×10 14
29
Phillips truss head self-tapping screw ST4×12 24
30
Allen pan head full thread bolt M6×25 4
31
Allen socket head full thread bolt M8×45 2
32
Allen flat head full thread bolt M8×25 8
34
Allen truss head half thread bolt M10×35×20 3
35
Flat washer Φ8 14
36
Flat washer Φ10 4
37
Foot pad 4
38
Front wheel 2
39
Powder metallurgy sleeve 2
41
Controller 1
42
Choke 1
43
Filter 1
44
Power adaptor 1
45
Front roller 1
46
Rear roller 1
47
Running deck 1
48
Running belt 1
49
Motor cover 1
50
Front motor cover 1
51
Rear cover 1
52
Foot rail 2
