53
Side cover 2
54
LED strip housing 2
55
LED strip 2
56
Choke/filter bracket 1
57
Rear wheel 2
58
Motor belt 1
59
Cushion 1 4
60
Brushless motor 1
61
Incline motor 1
62
Power switch 1
63
Reset Switch 1
64
Power cable buckle
1
65
Left PU handlebar 1
66
Right PU handlebar 1
67
Left outer handlebar cover 1
68
Left inner handlebar cover 1
69
Right outer handlebar cover 1
70
Right inner handlebar cover 1
71
Upper tray cover 1
72
Lower tray cover 1
74
Upper dashboard cover 1
75
Lower dashboard cover 1
76 Console neck cover
1
81
Incline handle pulse 1
82
Cylinder 1
84
Speed handle pulse 1
85 Main communication wire (main frame+upright) 1
87
Power communication wire 1
88
Power communication wire 1
89
Power communication wire 1
90
Side rail guider 16
91
Power cable buckle 3
92
Plastic flat pad 8
93
Safety key 1
94
Safety key socket 1
95
LED display 1
97 Inner expansion pipe 1
98
Outer expansion pipe 1
99
LED communication wire
(main frame+upright)
1
100
Power cord 1
101 Main communication wire (console) 1
102 LED communication wire (console) 1
103
Cushion1 2 2
104
Cushion1 3 2
107
Power connection wire 1
109
Handle pulse wire 1
111
Display bracket 1
112
Allen truss head bolt M8×40 2
113
Allen truss head full thread bolt M8×15 4
114
Display inner bracket 1
