29
in a normal
state
B
、
abnormal system
Contact the after
-
sales team for service
Buttons don’t
work
A
、
Some buttons are
damaged or invalid
Replace the buttons
B
、
All buttons are invalid
1
、
Replace button board, wires of
buttons 2,
main board 3 or console
No heart rate
data is shown
A
、
Handle pulse wire isn’t
assembled well, or handle
pulse wire is defected.
Check and connect it well, or replace the handle
pulse wire
B
、
Console
line fault
Replace the console
AA
(at
all window)
Safety key lost
Plug the safety key back
A1
(at TIME
window)
lower control board
connection fails.
1. Check if good connection between lower con-
troller and console, and each pin is properly in-
serted.
2. Check if any damage cables between lower
controller and console, change the cables
3. Change lower controller or console if above
cannot solve
A2
(at TIME
Window)
explosion-proof protection
1. Use volt meter to check whether the power
supply voltage is lower than 50% of the normal
voltage
2. Check if connecting motor, and reconnect the
motor cable.
3. Check if odor from controller, and change the
controller.
A3
(at TIME
window)
Abnormal speed sensor
1. Check if speed sensor correct installation
2. Check if speed sensor in good contact, if wire
in good condition
3. Change the speed sensor
A4
(at TIME
window)
Abnormal incline motor
1. Run the incline motor calibration: Unplug the
safety key, then hold the STOP key for 3sec-
onds to enter incline calibration. Plug the safety
key again, the incline will return to zero after
calibration completes.
2. If still error code, check if the wire is proper
connection
3. Change the incline motor
A5
(at TIME
window)
Over current
1. Power off for 20seconds, then power on
2. If still error code, check if roller proper function,
check if the running belt and deck good lubri-
cated
3. Change the controller
