CS-350WES
25
FUEL SYSTEM
4-3 Replacing primer
NOTE: It is possible to replace primer, as the
carburetor is in the place.
1. Remove fuel inlet pipe (B) from primer (A).
4-2 Checking fuel cap and strainer
1. Remove fuel cap.
2. Check fuel cap for cracks and O-ring (A) for cuts
or damages.
3. Remove connector (B) if defective, install a new
connector into center hole.
4. Pull fuel strainer (C) from fuel tank using a wire
hook and clean the fuel strainer. Replace with a
new one if defective or heavily soiled. Re-install fuel
cap.
B
A
A
B
C
(continued)
To Next Page
