DESCRIPTION CS-355T
24 X7503323507
© 01/2021 ECHO Incorporated
Improper sprocket guard assembly can result in serious injury,
and will cause severe saw damage if unit is started. Never start
or operate saw if brake band is not in place on clutch drum.
Always check chain brake operation after replacing guard. Do
not use saw if chain brake does not function properly.
Adjusting Chain Tension
Always loosen sprocket guard nuts before turning the chain tension
adjuster, otherwise the sprocket guard and tensioner will be
damaged.
1. Remove air cleaner cover and disconnect spark plug lead.
2. Loosen sprocket guard nuts
(A).
3. Hold the bar nose up, and turn
the adjuster (B) toward (+) until
chain contacts underside of the
bar.
