Page #17 background image
15
CS-620P
WARNING
•Afterchokecontrolknobispulledandthen
knob is returned to original position, throttle
remains a little open (latch condition).
•Ifengineisstartedinthislatchcondition,
chain starts to turn.
Do not start engine before chain brake is
activated.
CAUTION
•Afterstartingtheengine,immediately
squeeze and release throttle trigger for
disengaging throttle latch and returning
engine to idle, and pull front hand guard
towards the operator immediately.
(Chain brake unlocked position)
•Neverusethrottlelatchforcutting.
•Usethechainbrakeonlyinstartingorin
emergencies.
OPERATION
Start / Run
Ignition switch
Chain brake
Starter handle
Unlock chain brake
Throttle trigger
Choke
Throttle trigger lockout
Decompression device

Questions and Answers:

Echo CS-620P Specifications

General IconGeneral
Engine Displacement59.8 cc
Oil Tank Capacity300 ml
Weight6.2 kg
Chain Pitch3/8 in
Engine Power3.3 kW
Power Output4.4 bhp
Bar Length20 in
Bar Length Options16 in, 18 in, 20 in
Weight (without bar and chain)6.2 kg
Chain Gauge0.050 in
Oil Capacity300 ml
