Echo CS-620P User Manual

6
CS-620P
NOMENCLATURE OF PARTS
* If a decal cannot be read, a new one can be
ordered from your ECHO dealer.
19
14
15
17
16
5
4
8
7
10
11
12
3
2
1
X524-005770
9
21
6
22
20
23
18
13
3
24
25
X505-006660
Part Number X524-005770
Part Number X505-006660
REPLACEMENT BAR AND CHAIN
GUIDE BAR* CHAIN*
PART NO. PART NO.
16” 16D0PS3860 72LPX60CQ
18” 18D0PS3866 72LPX66CQ
20” 20D0PS3870 72LPX70CQ
24” 24D0PS3881 72LPX81CQ
27” 27D0PS3893 72LPX93CQ
*Or equivalent
Note:
There may be other replacement
components for achieving kickback
protection. For details, please refer
to the chain and bar combination
sheet shown in the instruction manual.

Echo CS-620P Specifications

General

Engine Displacement	59.8 cc
Oil Tank Capacity	300 ml
Weight	6.2 kg
Chain Pitch	3/8 in
Engine Power	3.3 kW
Power Output	4.4 bhp
Bar Length	20 in
Bar Length Options	16 in, 18 in, 20 in
Weight (without bar and chain)	6.2 kg
Chain Gauge	0.050 in
Oil Capacity	300 ml
