Echo CS-620P User Manual

23
CS-620P
CHAIN AND GUIDE BAR COMBINATION
The following combinations are recommended for model
CS-620P
.
GUIDE BAR
(Low-kickback)
Replacement guide bars.
The following guide bars may be considered to
have equivalent kickback energy.
• Sprocketnoseguidebarsofthesamelength
and nose radius, same pitch and having the
same number of teeth.
• Hardnoseguidebarsofthesamelengthand
nose radius as a sprocket nose bar.
SAW CHAIN
(Low-kickback)
CAUTION
Do not use replacement saw chain unless
it has been designated as meeting the ANSI
B175.1 kickback performance requirements,
when tested on the representative sample of
chainsawsbelow3.8c.i.d.speciedinANSI
B175.1.
NOTICE
LOW KICKBACK SAW CHAIN meets the
kickback performance requirements of ANSI
B175.1 (safety requirements for gasoline-
powered chain saws).
Guide bar Saw chain
Length mm (in.)
ECHO Part No.
Pitch mm (in.) ECHO Part No. Links
Symmetrical
406 (16) 16D0PS3860
9.53 (3/8)
72LPX60CQ 60
457 (18) 18D0PS3866 72LPX66CQ 66
508 (20) 20D0PS3870 72LPX70CQ 70
610 (24) 24D0PS3881 72LPX81CQ 81
686 (27) 27D0PS3893 72LPX93CQ 93

Echo CS-620P Specifications

General

Engine Displacement	59.8 cc
Oil Tank Capacity	300 ml
Weight	6.2 kg
Chain Pitch	3/8 in
Engine Power	3.3 kW
Power Output	4.4 bhp
Bar Length	20 in
Bar Length Options	16 in, 18 in, 20 in
Weight (without bar and chain)	6.2 kg
Chain Gauge	0.050 in
Oil Capacity	300 ml
