DESCRIPTION CS-7310P
22 X7503340002
© 11/21 ECHO Incorporated
Preparation for Use
Saw chain is sharp! Always wear gloves when handling
assembly, otherwise serious personal injury can result.
Guide Bar and Saw Chain Installation and Removal
1. Remove air cleaner cover and disconnect spark plug lead.
When removing sprocket guard,
loosen each nut one full turn,
then completely loosen each nut.
If one nut remains tight while the
other is fully loosened, nut will
not remain captive
2. Loosen sprocket guard nuts (A)
and remove sprocket guard (B).
3. Remove guide bar and saw
chain if necessary.
Note: See “Maintenance”
section for guide bar and
saw chain maintenance
procedures.
4. For initial setup, install spiked
bumpers. Bumper with chain
catcher (C) onto front of
chainsaw body, and bumper
without chain catcher (D) onto
clutch cover.
