CS-8000 TYPE1-E
MODEL CS-8000 TYPE1-E
Dimension L × W × H mm 421 × 244 × 311 (15.5 in. × 9.6 in. × 10.9 in.)
Mass Power head, dry kg 7.5 (16.5 lb.) Without chain and guide bar
Engine Type Air-cooled two-stroke single cylinder
Displacement mL (cm³) 80.7 (4.924 cu. in.)
Carburetor Diaphragm type
Magneto Flywheel magneto: CDI system
Spark plug NGK BPM7A
Starter Recoil starter
Power transmission Automatic centrifugal clutch
Fuel Mixture ratio 50 : 1 ratio with ECHO Power Blend X™, ISO-L-
EGD (ISO/CD 13738) and JASO M345-FC/FD two-
stroke, air-cooled engine oil.
Gasoline Use 89 octane unleaded.
Do not use fuel containing methyl alcohol, more than
10 % ethyl alcohol or 15 % MTBE.
Do not use alternative fuels such as E-20 or E-85.
Tank capacity L 0.82 (27.7 US. fl. oz.)
Oil Bar and chain ECHO bar and chain oil (or motor oil)
Tank capacity L 0.40 (13.5 US. fl. oz.)
Guide bar and
See page 21 for Chain and Guide Bar Combination
saw chain
Lubrication Adjustable automatic oil pump and manual oil pump
Engine speed Idle r/min 2800 - 3000
Clutch engagement r/min 3800
Wide open throttle r/min 11500 - 12500
Standard Front hand guard, Rear hand guard,
features Anti-vibration device, Spiked bumper,
Throttle control lockout, Chain brake,
Chain catcher, Spark arrestor muffler
STORAGE AFTER USE
* Technical data subject to change without notice.
TECHNICAL DATA
• Inspect and adjust every part of the chain saw.
- Completely clean every part and repair if
necessary.
- Apply thin coating of oil on metal parts to
prevent rust.
• Remove chain and guide bar.
• Drain fuel tank, pull starter slowly a few times to
drain fuel from carburetor.
• Pour a small amount of clean motor oil into spark
plug hole, pull starter and crank the engine until
piston reaches: TOP DEAD CENTER.
• Store in a dry area, free from dust.
WARNING
Do not store in an enclosure where fuel
fumes may accumlate or reach an open flame
or spark.
NOTE
• For future reference, you should keep this
Instruction manual and the Safety manual.
• If this Instruction manual or the Safety manual
has become illegible or is lost, please purchase
a new one from your ECHO dealer.
CAUTION
Do not lend or rent your chain saw without
the Instruction manual and Safety manual.
