23
DCS-5000
99922205708
© 08/2021 ECHO Incorporated
DESCRIPTION
Installing the Battery
Removing the Battery
1. Press front hand guard forward.
(Chain brake ACTIVATED position)
2. Align ridges on battery with groove
on chainsaw, and insert battery
until battery latch (G) locks and a
clicking sound is heard.
1. To remove battery, depress battery
latch (G), and slide battery out of
the chainsaw.
Installing and Removing the Battery
The battery comes partially charged from the factory and needs to be
fully charged before rst use.
Note: See separate Operator's Manual Packaged with the Battery.
The chainsaw will operate when the battery is installed, and the
trigger switch and trigger switch lockout are engaged. Make sure
the chainsaw is properly positioned to prevent loss of control and
possible serious injury.
Keep movable parts of the chainsaw off the ground and away
from objects that could become entangled.
G
