Echo GT-200R User Manual

20
LUBRICATION
Level 1.
Tools Required: 8mm Open end wrench, screwdriver, clean rag.
Parts Required: ECHO
®
LUBE
TM
8 oz. (P/N 91014) or Lithium Base
Grease.
1. Remove plastic shield.
2. Loosen bearing housing locating screw (A), at the top of the
housing, loosen mounting screw (B) and remove gear case from
drive housing.
3. Pull the flexible drive shaft (C) from the drive housing, wipe clean
and recoat with a thin coating [1/2 oz. (15 ml)] of grease.
4. Slide the flexible drive shaft back in the drive housing being careful
not to get dirt on the flexible drive shaft.
5. Install the bearing housing and shield.
A
B
C

Echo GT-200R Specifications

General

Engine Displacement	21.2 cc
Engine Type	2-stroke
Fuel Capacity	0.41 liters
Weight	10.1 lbs
Fuel Tank Capacity	14.9 fl. oz.
Starter System	Recoil
Power Output	0.7 kW
Shaft Type	Straight shaft
