27
GT-2150/2150S
Masses
unit without cutting attachment, empty tank kg 4.4 (4.8)
unit with specified cutting attachment, empty tank kg 4.6 (5.0)
unit with specified cutting attachment, full tank kg 4.9 (5.3)
Volume
fuel tank L 0.4
Cutting attachment
nylon line head F-4/8R
line diameter mm 2.4
line length m 2.5
thread M 8 × 1.25
Gear ratio
gear ratio and lubrication No reduction and shell
deipena or good quality lithium
grease
Rotational direction of output shaft seen from above Clockwise
External dimensions
length × width × height mm 1,535 × 205 × 370 (1,565 × 205 × 370)
Engine
type Air cooled two stroke single cylinder
engine displacement mL (cm
3
) 21.2
maximum shaft brake power, measured in
accordance with ISO 8893 kW 0.56
engine speed at maximum engine power r/min 7,500
recommended maximum engine speed r/min 10,000
output shaft speed r/min
recommended engine idling speed r/min 3,000
engine speed at beginning of clutch engagement r/min 3,800
carburettor Diaphragm type
Ignition Flywheel magneto - CDI system
spark plug CHAMPION RCJ-7Y
starter Recoil starter (GT-2150S ; START)
clutch Automatic centrifugal clutch
Fuel consumption
mixing ratio Regular grade petrol 25 parts : 1 part
(4%) an air cooled two stroke engine
oil of a reputable brand name
fuel consumption at maximum engine power L / h 0.56
specified fuel consumption at maximum
engine power g/(kW·h) 750
Sound pressure level
LpAav= dB(A) 96.3
Sound power level
LwAav= dB(A) 103
Vibration levels
idling m/s
2
7.0
racing m/s
2
9.2
SPECIFICATIONS
GT-2150(S)
