CONTENTS GT-225L
16 X7732272601
© 3/2019 ECHO Inc.
CONTENTS
The ECHO product you purchased has been factory pre-assembled for your
convenience. Due to packaging restrictions, some assembly may be
necessary.
After opening the carton, check for damage. Immediately notify your retailer
or ECHO Dealer of damaged or missing parts. Use the contents list to check
for missing parts.
ASSEMBLY
Shield Installation
Cut-off knife on debris shield has sharp edges. Avoid contact
when installing or removing line head.
Wear Gloves or personal injury may result:
◆ Cut-off knife is sharp.
◆ Gear case and surrounding area may be hot.
1. Remove wing nut (A), washer
(B), and bolt (C).
2. Snap the shield over the
bearing housing.
3. Install bolt (C), washer (B), and
wing nut (A).
1 Power Head / Drive Shaft Assembly
1 Operator’s Manual
1 Warranty Statement
1 Shield Assembly
Parts Required: Shield Assembly.
