HEDGE CLIPPER
OPERATOR'S MANUAL
27
HC-1500, Type 2E, HC-2400, 2410 (All)
Level 1.
Tools required: Grease Gun, Clean rag
Parts required: ECHO
®
LUBE
TM
8 oz. (P/N 91014) or Lithium Based
Grease.
1. Clean dirt from the grease fitting.
2. Carefully pump grease into fitting.
DO NOT force grease. Too
much pressure will force grease past seals and cause damage.
BLADE STIFFENER REMOVE/INSTALL
Level 2.
Tools required: (2) 13mm Open End
Parts Required: None
WARNING DANGER
Hedge Clipper blades are very sharp. Wear gloves to protect
hands.
1. Disconnect spark plug wire from spark plug.
2. Hold blade bolt head under blade assembly. Remove blade locknut
from top side turning counter clockwise.
3. Repeat step 2 for remaining blade nuts.
NOTE
Locking ability of Hedge Clipper blade nuts will diminish each time
they are removed. Replace blade nuts if threading resistance is not
felt when installing locknuts.
